Home >> Jeep >> 2002 >> Grand Cherokee 2WD Laredo V8-4.7L >> Repair and Diagnosis >> A L L Diagnostic Trouble Codes ( DTC ) >> Testing and Inspection >> Manufacturer Code Charts >> Interior Lighting >> Courtesy Lamps Inoperative From Dome Lamp Switch Only

Courtesy Lamps Inoperative From Dome Lamp Switch Only

Tests 1 - 3:





SYMPTOM
COURTESY LAMPS INOPERATIVE FROM DOME LAMP SWITCH ONLY

POSSIBLE CAUSES
- DTC present
- Left multi-function switch dimmer open
- BCM dimmer inoperative
