Mode Select Switch Open (AZC) (Stored)

Test 1:

SYMPTOM
MODE SELECT SWITCH OPEN (AZC) (STORED)

WHEN MONITORED
Ignition in RUN and IOD fuse installed.

SET CONDITION
This condition is set if the AZC reads the mode select switch value and it is above 250 A/D counts.

POSSIBLE CAUSES
- AZC module stored codes present
- Stored codes test complete
