Rear Washer Motor Test
WARNING: This page is about a different car, the 1995 Jeep Grand Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
- Unplug washer pump connector, under washer reservoir in engine compartment. Check for continuity between harness connector terminal "A" (Black wire) and ground. If no continuity exists, repair open circuit in Black wire to ground.
- Connect jumper wire between terminal "A" on washer pump and a good ground. Supply battery voltage to washer pump terminal "B", using jumper wire with a 15-amp in-line fuse. See Fig 1 . Pump should operate. If pump is inoperative, replace pump.
