Control Diagram
WARNING: This page is about a different variant/trim than selected.
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
A = HARDWIRED
.
| ITEM |
DESCRIPTION |
| 1 |
Powertrain Control Module (PCM) |
| 2 |
Front (1) High Pressure (HP) fuel pump |
| 3 |
Rear (2) HP fuel pump |
| 4 |
Fuel injector (8 off) |
| 5 |
Ground |
| 6 |
Supply |
| 7 |
Fuel Rail Pressure and Temperature (FRPT) sensor |
