Auto Stop/Start Warning Indicator (If Equipped)
WARNING: This page is about a different variant/trim than selected.
On vehicles with auto stop/start system, an auto stop/start warning indicator is located in the Instrument Cluster (IC). The auto stop/start warning indicator illuminates green when the engine stops during an auto stop/start cycle, then goes off when the engine restarts. The auto stop/start warning indicator illuminates white when the auto stop/start system is disabled. The auto stop/start warning indicator is controlled by a High Speed (HS) Controller Area Network (CAN) powertrain systems bus message from the Powertrain Control Module (PCM).
