| 60.35.05 |
SUSPENSION UNIT - RENEW |
2000 CC, INGENIUM DIESEL, 2WD |
2.8 |
| 60.35.05 |
SUSPENSION UNIT - RENEW |
2000 CC, INGENIUM DIESEL, 4WD |
4 |
| 60.35.05 |
SUSPENSION UNIT - RENEW |
2000 CC, INGENIUM PETROL, 2WD |
2.8 |
| 60.35.05 |
SUSPENSION UNIT - RENEW |
2000 CC, INGENIUM PETROL, 4WD |
4 |
| 60.35.05 |
SUSPENSION UNIT - RENEW |
3000 CC, AJ V6 (AJ126), 4WD |
4.1 |
SPECIAL TOOL(S)
303-021
Engine support bracket |
|
JLR-204-793
Ball Joint Splitter |
|
GENERAL EQUIPMENT
| EQUIPMENT NAME |
| Transmission jack |
PART(S)
| STEP |
PART NAME |
QUANTITY |
| Step 17 |
Steering column lower shaft lower bolt |
1 |
| Step 22 |
Wheel knuckle nut |
2 |
| Step 23 |
Shock absorber lower bolt |
2 |
| Step 24 |
Front subframe to body bolts |
6 |
| Step 27 |
Steering gear bolts |
4 |
| Step 28 |
Stabilizer bar link retaining nuts |
4 |
| Step 29 |
lower control arm nut(s) and bolt(s) |
2 |
| Step 30 |
Upper control arm to subframe nuts and bolts |
2 |
