Reagent Warning Indicator
WARNING: This page is about a different car, the 2018 Jaguar XE and 2017 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Dependent on the warning stage, the reagent warning indicator symbol will be amber or red.
There are three possible routes to receive a fault message on the IC:
- Low Diesel Exhaust Fluid (DEF) volume in the tank
- Incorrect DEF quality supplied to the SCR System
- Efficiency of the SCR system is reduced in the event of a system fault.
