Component Location - All Markets: Notes
WARNING: This page is about a different variant/trim than selected.
| ITEM | DESCRIPTION |
|---|---|
| 1 | Clutch pedal position sensor |
| 2 | Accelerator Pedal Position (APP) sensor |
| 3 | Clutch Bottom of Travel (BOT) switch |
| 4 | Brake pedal switch |
| 5 | Transmission Control Switch (TCS) - Automatic transmission only |
| 6 | Diesel exhaust fluid heater control unit |
| 7 | Diesel exhaust fluid tank module |
| 8 | Ambient Air Temperature (AAT) sensor - located in left door mirror |
| 9 | Automatic Temperature Control Module (ATCM) |
| 10 | Body Control Module/Gateway Module (BCM/GWM) assembly |
| 11 | Fuel Pump Driver Module |
| 12 | Powertrain Control Module (PCM) |
| 13 | Transmission Control Module (TCM) - Automatic transmission only |
| 14 | Reverse switch - Manual transmission only |
| 15 | Gear selector position switch |
| 16 | Water in fuel sensor |
| 17 | Generator |
| 18 | Starter motor |
| 19 | Active grille air shutter motor |
| 20 | Radiator outlet temperature sensor |
| 21 | Glow plug control module |
| 22 | Brake vacuum sensor |
| 23 | Engine cooling fan control module |
