Rear Door Window (G1829871): Removal

WARNING: This page is about a different car, the 2020 Jaguar XE and 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION: Lay the glass on felt covered supports. Do not stand on edge as this can cause chips which subsequently develop into cracks.
NOTE:
  • This procedure contains illustrations showing certain components removed to provide extra clarity.
  • This procedure contains some variation in the illustrations depending on the vehicle specification, but the essential information is always correct.
  1. Remove the rear door fixed window.

    Refer to: REAR DOOR FIXED WINDOW

  2. G14011066Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
    • Release the front door window.

      Special Tool(s): 501-114

    • Remove the front door window.
