Hood Deployment Control (G1829863): Removal
WARNING: This page is about a different car, the 2020 Jaguar XE and 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
WARNING:
- To avoid accidental deployment, the restraints control module backup power supply must be depleted. Wait at least two minutes after disconnecting the battery ground cable(s) before commencing any repair or adjustment to the supplemental restraint system (SRS), or any component(s) adjacent to the SRS sensors. Failure to follow these instructions may result in personal injury.
- Never probe the electrical connectors of air bag modules or any other supplemental restraint system component. Failure to follow this instruction may result in personal injury.
NOTE:
Removal steps in this procedure may contain installation details.
- Make the Supplemental restraint system (SRS) safe.
Refer to: STANDARD WORKSHOP PRACTICES
- Refer to: STARTUP BATTERY DISCONNECT AND CONNECT
Torque : 10Nm
