Image Processing Module (IPMA)
WARNING: This page is about a different car, the 2020 Jaguar XE and 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
The Image Processing Module (IPMA) is able to detect road lane markings, traffic sign markings and monitor the road ahead for Lane Departure Warning (LDW), Lane Keep Assist (LKA), Traffic Sign Recognition (TSR) and Autonomous Emergency Braking (AEB) systems.
The IPMA is a module located in the rear view mirror, that has two built in forward facing cameras. The IPMA receives an ignition supply from the Rear Junction Box (RJB) and information can be exchanged from the IPMA via the High Speed (HS) Controller Area Network (CAN) chassis bus to the other modules.
The IPMA also hosts the software for:
- Driver Drowsiness Detection (DDD) system
- Intelligent Speed Limiter (ISL) system. For additional information, Refer to: SPEED CONTROL
