Brake Caliper - INGENIUM I4 2.0L Diesel (G1822042): Removal

WARNING: This page is about a different car, the 2020 Jaguar XE and 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: If the brake pad wear warning light has been activated, a new brake pad wear sensor must be installed.

CAUTION: If brake fluid is spilt on the paintwork, the affected area must be immediately washed down with cold water.

NOTE: Make sure that all openings are sealed.

WARNING: Make sure to support the vehicle with axle stands.

Raise and support the vehicle.
Remove the wheel and tire.
Refer to: WHEEL AND TIRE
Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
NOTE: The brake pad wear indicator sensor is easily damaged. Do not use a lever to remove the sensor. Use fingers only.

Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

Inspect the brake pad wear sensor for signs of wear or damage. Install a new sensor if necessary.
CAUTION:
- Inspect the brake hose sealing washers for signs of damage, if damage is present discard the sealing washers.
- Be prepared to collect escaping fluids.
NOTE: Make sure that all openings are sealed.

Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC

Remove the flexible brake hose.
Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
