Warning Symbols On Vehicles

WARNING: This page is about a different car, the 2020 Jaguar XE and 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.

Decals showing warning symbols will be found on various vehicle components.

These decals must not be removed. The warnings are for the attention of owners/operators and persons carrying out service or repair operations on the vehicle.

The most commonly found decals are reproduced below together with an explanation of the warnings.

G11296886Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
  1. Components or assemblies displaying the warning triangle and open book symbol advise consultation of the relevant article of the owners handbook before touching or attempting adjustments of any kind.
    G11296887Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
  2. Components or assemblies displaying the warning triangle with the electrified arrow and open book symbol give warning of inherent high voltages. Never touch these with the engine running or the ignition switched on. See ELECTRIC SHOCK  in this subarticle.
    G11296888Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
  3. Jaguar vehicles and replacement parts which contain asbestos are identified by this symbol. See ASBESTOS  in this subarticle.
    G11296889Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
  4. Components or assemblies displaying this symbol give warning that the component contains a corrosive substance. See ACIDS AND ALKALIS  in this subarticle.
    G11296890Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
  5. Vehicles displaying the caution circle with a deleted lighted match symbol, caution against the use of naked lights or flames within the immediate vicinity due to the presence of highly flammable or explosive liquids or vapors. See FIRE  in this subarticle.
    G11319974Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
  6. All vehicles with the passenger air bag installed from the factory have a warning sticker attached to the instrument panel, prohibiting the use of rear facing child seats in the front seating position. Failure to follow this instruction may result in personal injury.
