Hood Latch Panel (G1817620): Removal
WARNING: This page is about a different car, the 2019 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Removal steps in this procedure may contain installation details.
-
NOTE:
Repeat the procedure for the other side.
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
Torque: 9 Nm
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
Torque: 10 Nm
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
Torque: 10 Nm
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
Repeat step for other side.
Torque: 9 Nm
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
Repeat step for other side.
Torque: 25 Nm
 Courtesy of JAGUAR LAND ROVER NORTH AMERICA, LLC
|
Torque: 25 Nm
