Removal And Installation: Removal

WARNING: This page is about a different car, the 2018 Jaguar XE and 2017 Jaguar XE. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
  • This procedure contains some variation in the illustrations depending on the vehicle specification, but the essential information is always correct.
  • This procedure contains illustrations showing certain components removed to provide extra clarity.
  1. Disconnect the startup battery ground cable.

    Refer to: Battery Disconnect and Connect .

  2. Raise and support the vehicle on a suitable 2 post lift.

    Refer to: Lifting .

  3. Drain the coolant system.

    Refer to: Cooling System Draining and Vacuum Filling .

  4. Remove the exhaust manifold.

    Refer to: Left Exhaust Manifold .

  5. CAUTION: Be prepared to collect escaping coolant.
    G11307274
    • Disconnect the electrical connector.
    • Remove the block heater.
