Exhaust Manifold RH (G1271895): Removal
WARNING: This page is about a different car, the 2013 Jaguar XJ, 2012 Jaguar XJ, 2011 Jaguar XJ, and 2010 Jaguar XJ. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
- Some variation in the illustrations may occur, but the essential information is always correct.
- Some illustrations may show the engine removed for clarity.
All vehicles
- Refer to: Battery Disconnect and Connect (414-01, General Procedures).
- Raise and support the vehicle.
- Refer to: EXHAUST SYSTEM (G1269296)
.
Right-hand drive vehicles
- Refer to: STEERING GEAR - RWD (G1875290)
.
All vehicles
-
CAUTION:
- Discard the bolts.
- LH illustration shown, RH is similar.
NOTE:- Discard the gasket.
- Make sure that the position of the spacers is noted before removal of the manifold.
-
NOTE: Do not disassemble further if the component is removed for access only.
