Component Location

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2017 Jaguar XJ, 2016 Jaguar XJ, 2015 Jaguar XJ, 2014 Jaguar XJ, and 2013 Jaguar XJ. However, it is still accessible from the selected car via links, so may be relevant.
G11284193
ITEM DESCRIPTION
1 Right halfshaft
2 Front halfshaft support bracket
3 Engine oil pan
4 Front driveshaft
5 Front differential assembly
6 Left halfshaft
