Removal And Installation: Installation

WARNING: This page is about a different car, the 2015 Jaguar XF, 2014 Jaguar XF, and 2013 Jaguar XF. However, it is still accessible from the selected car via links, so may be relevant.

All vehicles

- Install a new nut and tighten to 48 Nm.
Torque Specification: 48 Nm
- Torque Specification: 63 Nm
- Install a new locknut.
Right-hand drive vehicles
Torque Specification: 100 Nm
NOTE: Note the fitted position.
- Torque Specification: 35 Nm
All vehicles
Refer to: Air Deflector (Front End Body Panels, Removal and Installation).
WARNING: Do not work on or under a vehicle supported only by a jack. Always support the vehicle on safety stands.

Lower the vehicle on the lift.
Refer to: Battery Disconnect and Connect (Battery, Mounting and Cables, General Procedures).
