Component Location - Sheet 3 Of 4

WARNING: This page is about a different car, the 2015 Jaguar XF, 2014 Jaguar XF, and 2013 Jaguar XF. However, it is still accessible from the selected car via links, so may be relevant.
G11417131
ITEM DESCRIPTION
1 Turbocharger boost pressure and temperature sensor
2 Cooling fan control module
3 Pre-catalyst Heated Oxygen Sensor (HO2S)
4 Post catalyst HO2S
5 Air Conditioning (A/C) pressure sensor
