Removal And Installation: Removal

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2014 Jaguar XKR-S, 2014 Jaguar XKR, and 2013 Jaguar XKR-S. However, it is still accessible from the selected car via links, so may be relevant.
NOTE: Removal steps in this procedure may contain installation details.
  1. Refer to: Battery Disconnect and Connect
  2. WARNING: Make sure to support the vehicle with axle stands.

    Raise and support the vehicle.

  3. Refer to: Left Camshaft

  4. Refer to: Exhaust Manifold

  5. NOTE: Some variation in the illustrations may occur, but the essential information is always correct.
    G11285125
  6. CAUTION: Discard the seals.
    G11284960
  7. CAUTION: Discard the bolts.
    G11284964
  8. NOTE: Discard the gasket.
G11284965
