Convertible Top Rear Panel Lower Weatherstrip: Removal

WARNING: This page is about a different car, the 2011 Jaguar XKR, 2011 Jaguar XK, 2010 Jaguar XKR, and 2010 Jaguar XK. However, it is still accessible from the selected car via links, so may be relevant.
  1. Open the convertible top to the position shown.
    • Depress the switch.
      GJ0009610
  2. Release the rear edge of the convertible top rear panel lower weatherstrip.
    • Remove the 21 Torx screws.
    • Remove the main carrier.
      GJ0010036
  3. Open the convertible top to the position shown.
    • Depress the switch.
      GJ0025646
    4. CAUTION: Make sure that filings and swarf do not enter the component.
    CAUTION: LH illustration shown, RH is similar.
  4. Remove the convertible top rear panel lower weatherstrip C-post carriers.
    • Release the seal.
    • Drill out the 6 rivets.
      GJ0010467
    5. CAUTION: LH illustration shown, RH is similar.
  5. Remove the convertible top rear panel lower weatherstrip.
    • Carefully release the convertible top rear panel lower weatherstrip from the outer material.
      GJ0010468
