Removal And Installation: Removal
WARNING: This page is about a different car, the 2015 Jaguar XK, 2014 Jaguar XK, 2013 Jaguar XK, and 2012 Jaguar XK. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Removal steps in this procedure may contain installation details.
- Refer to: Battery Disconnect and Connect
- Refer to: Engine Cover - 5.0L
Torque Specification: 10 Nm
Torque Specification: 10 Nm
Torque Specification: 18 Nm
CAUTION:
Do not attempt to clean the throttle body bore, build up of deposits reduces air leakage past the throttle plate at the fully closed position.
NOTE:
Clamp the hose to minimize coolant loss.
