Brake Pads - Vehicles With: High Performance Brakes (G1073720): Installation

  1. NOTE: The brake pad wear sensor retaining tang must be installed to the sensor prior to installation to the brake pad.
    G11423637
  2. To install, reverse the removal procedure.
  3. Repeat the above procedure on the opposite side.
