Passenger Airbag Deactivation Warning Lamp

The passenger air bag deactivation indicator is installed on the center switch pack of the instrument panel. When appropriate, the indicator illuminates to advise front seat occupants that the passenger air bag is disabled. Operation of the indicator is controlled by the RCM. The RCM illuminates the indicator when:

• There is a fault with the passenger air bag firing circuit(s).
• The passenger air bag is de-activated with the passenger air bag deactivation switch (where fitted).
• Required by passenger seat occupant monitoring (see below).
