LH Multifunction Switch
| ITEM | DESCRIPTION |
|---|---|
| 1 | High beam |
| 2 | Lighting control rotary switch |
| 3 | RH turn signal indicator |
| 4 | Headlamp flash |
| 5 | LH turn signal indicator |
| 6 | Trip computer function button |
The LH multifunction switch controls the following windshield wiper functions:
- Turn signal indicators
- Side lamps
- Headlamps
- Auto lamps
- High/low beam
- Headlamp flash
- Headlamp timer
- Trip computer.
The switch is located in a slot in the clockspring and secured with 2 plastic clips.
