Removal And Installation: Installation

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2015 Jaguar XK, 2014 Jaguar XKR-S, and 2014 Jaguar XKR. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the convertible top assembly.
    • Tighten the nuts to 25 Nm.
    • Connect the electrical connectors.
  2. Align the convertible top assembly.

    For additional information, refer to: Convertible Top Alignment

  3. G11524387

    Close the convertible top to the position shown.

    4. NOTE: Support the convertible top compartment lid.

  4. Attach the convertible top compartment lid RH lift cylinder.

    • Secure with the clips.
  5. Secure the convertible top fluid lines and harness.
    • Secure the fluid line and harness clips.
    • Connect the electrical connector.
    • Install new cable ties.
  6. G11524608

    Open the convertible top to the position shown.

  7. Secure the convertible top hydraulic pump.
    • Tighten the bolts to 8 Nm.
  8. Connect the convertible top hydraulic pump electrical connectors.
    9. NOTE: The ignition must be switched off.
  9. G11524603

    Tighten the convertible top system pressure Allen bolt.

    • Tighten to 2 Nm.
  10. Install the RH loadspace trim panel.

    For additional information, refer to: Loadspace Trim Panel - Convertible

  11. Install the rear quarter trim panels.

    For additional information, refer to: Rear Quarter Trim Panel - Convertible
