Removal And Installation: Removal

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2015 Jaguar XK, 2014 Jaguar XKR-S, and 2014 Jaguar XKR. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the cover and disconnect the battery ground cable.

    For additional information, refer to: BATTERY, MOUNTING AND CABLES -- XK/X150 (Specifications).

  2. Make the SRS system safe.

    For additional information, refer to: AIRBAG DISPOSAL  (Supplemental Restraint System (SRS) Depowering and Repowering, General Procedures).

  3. Remove the rear seat backrest.

    For additional information, refer to: Rear Seat Backrest (Removal and Installation).

  4. G11549282

    Release the rear seat backrest trim panel.

    • Remove the 2 clips.
    • Remove the 2 bolts.
    • Position the rear seat backrest trim panel aside.
  5. G11504262

    Remove the rear seat backrest retaining bracket.

    • Remove the 2 nuts and 2 bolts.
G11504263

Remove the roll over protection unit.
