Drivers Memory Seat

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2015 Jaguar XK, 2014 Jaguar XKR-S, and 2014 Jaguar XKR. However, it is still accessible from the selected car via links, so may be relevant.

The seat control module can store up to 3 different driver seating, mirror and steering column positions. The numbered memory and single memory store switches control memory storage and recall operations. Each switch is a momentary action push switch.

The seat control module broadcasts memory switch selections on the medium speed CAN (controller area network) bus, for storage and recall of the door mirror and steering column positions by the door modules and instrument cluster respectively.

G11524232
