Removal And Installation: Removal

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2015 Jaguar XK, 2014 Jaguar XKR-S, and 2014 Jaguar XKR. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim panel.

    For additional information, refer to: Front Door Trim Panel (Removal and Installation).

  2. G11524068

    Remove the front seat control switch.

    • Remove the 4 Torx screws.
    • Disconnect the electrical connector.
