Removal And Installation: Removal
WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2015 Jaguar XK, 2014 Jaguar XKR-S, and 2014 Jaguar XKR. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Removal steps in this procedure may contain installation details.
- Refer to: Battery Disconnect and Connect (General Procedures).
-
WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.
- Refer to: Cooling System Partial Draining and Vacuum Filling (General Procedures).
- Refer to: Air Cleaner Outlet Intermediate Pipe LH (Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).
- Refer to: Air Cleaner Outlet Intermediate Pipe RH (Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).
- Refer to: Radiator Splash Shield (Front End Body Panels, Removal and Installation).
Torque Specification: 7 Nm
Torque Specification: 25 Nm
Torque Specification: 23 Nm
-
CAUTION: Make sure to protect the paintwork.
Torque Specification: 30 Nm
Torque Specification: 5 Nm
Torque Specification: 7 Nm
-
NOTE: Do not disassemble further if the component is removed for access only.
Torque Specification: 7 Nm
