Removal And Installation: Removal

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2015 Jaguar XKR-S, 2015 Jaguar XKR, 2015 Jaguar XK, 2014 Jaguar XKR-S, and 2014 Jaguar XKR. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the pedestrian protection hood actuator and bracket.

    For additional information, refer to: Pedestrian Protection Hood Actuator LH  And Pedestrian Protection Hood Actuator RH

  2. See Figure
    G11549418

    Remove the pedestrian protection latch actuator.

    • Remove and discard the 2 Torx bolts.
    • Disconnect the electrical connector.
