Electric Booster Heater (G1448003): Removal
WARNING: This page is about a different car, the 2015 Jaguar XF, 2014 Jaguar XF, and 2013 Jaguar XF. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
- Removal steps in this procedure may contain installation details.
- Some variation in the illustrations may occur, but the essential information is always correct.
All vehicles
- Disconnect the battery ground cable.
Refer to: Specifications (Battery, Mounting and Cables, Specifications).
- Refer to: Climate Control Assembly (Removal and Installation).
Right-hand drive vehicles
-
CAUTION: Take extra care not to damage the clips or screw threads. Failure to follow this instruction may result in damage to the climate control assembly.
Torque Specification: 1.3 Nm
-
CAUTION:
- Take care not to damage the O-ring seals during installation.
- A new O-ring seal is to be installed.
Torque Specification: 5.3 Nm
-
CAUTION:
- Take care not to damage the O-ring seals during installation.
- A new O-ring seal is to be installed.
Torque Specification: 3.5 Nm
Torque Specification: 1.5 Nm
Torque Specification: 9 Nm
All vehicles
