Brake Pedal: Installation

Install brake pedal to pedal housing.
- Apply grease to pivot bush and pivot pin.
- Align brake pedal in pedal housing.
- Install pivot pin.
- Install nut and tighten to 15-20 Nm.

  Fig 1: Installing Brake Pedal To Pedal Housing

  CAUTION: Make sure the BPP switch ratchet adjuster is fully released before installing.
Install the BPP switch.
- Tighten to 3 Nm.

  Fig 2: Installing BPP Switch
Install the brake booster and brake master cylinder. Refer to BRAKE BOOSTER AND BRAKE MASTER CYLINDER
