Steering Wheel Theft Deterrent Lock Replacement

WARNING: This page is about a different car, the 2007 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View of Steering Wheel Theft Deterrent Lock

Courtesy of GENERAL MOTORS CORP.

Steering Wheel Replacement

Callout	Component Name
Preliminary Procedure Remove the theft deterrent module. Refer to Theft Deterrent Module Replacement .
1	Ignition and Start Switch Bolt NOTE: Refer to Fastener Notice . 1.5 N.m (13 lb in)
2	Steering Wheel Theft Deterrent Lock Procedure Disconnect any electrical connectors as needed. Release the steering wheel theft deterrent lock tab using the appropriate tool to remove it from the ignition lock cylinder case.

Callout

Component Name

Preliminary Procedure

Remove the theft deterrent module. Refer to Theft Deterrent Module Replacement .

Ignition and Start Switch Bolt

NOTE: Refer to Fastener Notice .

1.5 N.m (13 lb in)

Steering Wheel Theft Deterrent Lock

Procedure

Disconnect any electrical connectors as needed.
Release the steering wheel theft deterrent lock tab using the appropriate tool to remove it from the ignition lock cylinder case.
