Shift Lever Replacement

WARNING: This page is about a different car, the 2007 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View of Turn Signal Multifunction Switch

Courtesy of GENERAL MOTORS CORP.

Turn Signal Multifunction Switch Replacement

Callout	Component Name
1	Shift Lever Bolt Procedure Use gentle pressure to disengage the shift lever boot from the steering column trim covers.
2	Shift Lever Bolt NOTE: Refer to Fastener Notice . Tighten 20 N.m (15 lb in)
3	Shift Lever

Callout

Component Name

Shift Lever Bolt

Procedure

Use gentle pressure to disengage the shift lever boot from the steering column trim covers.

Shift Lever Bolt

NOTE: Refer to Fastener Notice .

Tighten

20 N.m (15 lb in)

Shift Lever
