DTC 41: Fl Isolation Solenoid Coil Failure (Flash Out) C0245, C0247 (Serial Communications)

Fig 1: Diagnosis Procedure - FL Isolation Solenoid Coil Failure (DTC 41 (Flash Out) / C0245, C0247 (Serial Communications)
G02805094Courtesy of ISUZU MOTOR CO.
