Component Locations
COMPONENT LOCATIONS (1)
| Component | Location | ||||
|---|---|---|---|---|---|
| Amigo & Rodeo | |||||
| Alarm & Relay Control Unit | Above Right Kick Panel | ||||
| Fuse/Relay Box | Right Side Of Engine Compartment, On Inner Fender | ||||
| Horns | Behind Right Side Of Grille | ||||
| Hombre | |||||
| Horn Relay | In UBEC | ||||
| Horns | |||||
| "A" Note | In Left Fenderwell | ||||
| "F" Note | In Right Fenderwell | ||||
| Instrument Panel Fuse Block | Near Left Door Jamb, Left Of Instrument Panel | ||||
| Underhood Bussed Electrical Center (UBEC) | Over Left Fenderwell | ||||
| Trooper | |||||
| Fuse/Relay Box | Right Side Of Engine Compartment, On Inner Fender | ||||
| Horns | Behind Right Headlight | ||||
|
|||||
