CAUTION:
DO NOT spill brake fluid on painted surfaces or damage to finish will result. DO NOT place fingers in front of piston when air pressure is used for removal.
NOTE:
For exploded views of disc brake calipers, see Figure
and Figure
.
Fig 1: Exploded View Of Front Disc Brake Caliper (Typical)
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Fig 2: Exploded View Of Rear Disc Brake Caliper (Typical)
