Rocker Arm Shaft Assembly: Removal

Remove valve cover. Starting with outer nuts and working inward, loosen rocker arm shaft brackets. See Figure. Disassemble rocker arm shaft assembly by removing springs from shafts. Remove rocker arm brackets and rocker arms. Label all components for reassembly reference.
