Exploded View
WARNING: This page is about a different variant/trim than selected.
|
1. |
Front suspension member |
2. |
Stopper bushing |
3. |
Transverse link |
|
4. |
Insulator (VK56VD) |
5. |
Upper link |
6. |
Stopper rubber |
|
Refer to Components for symbols in the figure. |
|||||
