When New Cylinder Block Is Used

Check the cylinder bore grade ("1", "2" or "3") on rear side of cylinder block, and select piston of the same grade.

GNSJPBIA2284Z-284Courtesy of NISSAN NORTH AMERICA, INC.

A

: Bearing housing grade No. 1

B

: Bearing housing grade No. 2

C

: Bearing housing grade No. 3

D

: Bearing housing grade No. 4

E

: Bearing housing grade No. 5

F

: Cylinder bore grade No. 1

G

: Cylinder bore grade No. 2

H

: Cylinder bore grade No. 3

I

: Cylinder bore grade No. 4

J

: Cylinder bore grade No. 5

K

: Cylinder bore grade No. 6

L

: Cylinder bore grade No. 7

M

: Cylinder bore grade No. 8

SYMBOL

: Engine front
NOTE: Piston is available with piston pin as a set for the service part.
