Exploded View With Torque Specifications

WARNING: This page is about a different car, the 2016 Infiniti Q50. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of NISSAN NORTH AMERICA, INC.

Needle bearing	Snap ring	Front carrier assembly
Needle bearing	O-ring	Seal ring
Input clutch drum	Input clutch dish plate	Input clutch driven plate
Input clutch drive plate	Input clutch retaining plate	Snap ring
Rear internal gear
: Always replace after every disassembly.
: Apply ATF.
: Apply petroleum jelly.
