Component Parts Location: Notes
WARNING: This page is about a different car, the 2016 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.
 Courtesy of NISSAN NORTH AMERICA, INC.
|
| 1. |
BCM (view with combination meter removed) |
2. |
Stop lamp switch |
3. |
Shift lock release button (view with center console removed) |
| 4. |
Shift lock solenoid (view with center console removed) |
5. |
Park position switch (view with center console removed) |
|
|
