Exploded View With Torque Specifications

WARNING: This page is about a different car, the 2016 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Front Lower Link With Torque Specifications

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Cap	2.	Shock absorber insulator	3.	Bound bumper
4.	Rear shock absorber	5.	Rear knuckle	6.	Front lower link
7.	Rear suspension member		Front
