Required Tools

The following ICC sensor cone alignment tool J-51093 is necessary to perform the ICC sensor initial vertical alignment:

• ICC sensor cone alignment tool.
  Fig 1: Identifying Center Release Button, Plunger, Level, Suction Cup

  Courtesy of NISSAN NORTH AMERICA, INC.

1. Center release button
2. Plunger
3. Level
4. Suction cup
