Exploded View With Torque Specifications

WARNING: This page is about a different car, the 2016 Infiniti QX60. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Control Cable With Torque Specifications

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Bracket B	2.	Lock plate	3.	Transaxle assembly
4.	Bracket A	5.	Control cable	6.	CVT shift selector assembly
A:	Manual lever	B:	Grommet
