Removal and Installation: Removal

  1. Remove back pillar finisher. Refer to "BACK PILLAR FINISHER: REMOVAL AND INSTALLATION ".
    CAUTION: Do not reuse back pillar finisher.
  2. Remove rear speaker bolts (A).
  3. Remove bracket (2), then remove rear speaker (3).
    Fig 1: Identifying Rear Speaker, Bracket And Mounting Bolts
    G08855108Courtesy of NISSAN NORTH AMERICA, INC.
