Removal and Installation: Removal

  1. Remove the instrument lower panel LH. Refer to "REMOVAL AND INSTALLATION ".
  2. Remove screw (↓ ).
  3. Disconnect the harness connector (A) from the warning buzzer (1).
  4. Remove the warning buzzer (1).
    Fig 1: Identifying Harness Connector And Warning Buzzer
    G08857553Courtesy of NISSAN NORTH AMERICA, INC.
