Home >> Infiniti >> 2012 >> G37 IPL, Automatic Trans >> Repair and Diagnosis >> Accessories & Equipment >> Gauges & Instrument Panels >> Meter, Warning Lamp & Indicator (Coupe) >> System Description >> Meter System >> Shift Position Indicator >> SHIFT POSITION INDICATOR: Component Parts Location

SHIFT POSITION INDICATOR: Component Parts Location

Fig 1: Shift Position Indicator Components Location

G08241497

Courtesy of NISSAN NORTH AMERICA, INC.
