Meter, Warning Lamp & Indicator -- G37 Convertible
>>
System Description
>>
Meter System
>>
Engine Coolant Temperature Gauge
>>
ENGINE COOLANT TEMPERATURE GAUGE : Component Parts Location
ENGINE COOLANT TEMPERATURE GAUGE : Component Parts Location
Fig 1: Identifying Engine Coolant Temperature Gauge Component Parts Location
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
